scoot overview

scoot is the compositor: the process that draws every window, takes every input, and arranges windows in sideways-scrolling columns. The bar, the wallpaper daemon and the desktop profile are separate pieces that talk to it — this section is the compositor itself: launching it, configuring it, driving it.

How scrolling columns work

Windows sit in columns; columns form a strip that scrolls sideways. A new window never covers an old one — the strip grows and the view follows:

┌────────┐  ┌────────┐  ┌────────┐
│ term 1 │  │ term 2 │  │ term 3 │  ◀── you are here
└────────┘  └────────┘  └────────┘
◀────────── the strip scrolls ──────────▶

• Focus follows position: Super+h / Super+l walk columns, Super+j / Super+k walk windows stacked inside one column.
• Super+1…Super+9 jump to workspaces; each workspace is its own strip, each output its own set of workspaces — nothing scrolls across a monitor boundary.
• Super+r cycles the focused column’s width through [layout] column_widths.
• Dialogs, transient windows and fixed-size windows float above the strip instead of tiling (Windows); everything else tiles, always.

No titlebars by design: the focused window gets a colored ring drawn around it in the layout’s own gap (Appearance).

Launch it three ways

The backend flag chooses how scoot presents what it drew (the renderer flag — pixman or GLES — chooses what draws it; see Backends and rendering):

Flag	What happens	Use it to
--nested	scoot runs as a window inside your current desktop	try everything safely; the host owns size and scale
--tty	scoot drives real DRM/KMS hardware on a console	daily-drive on hardware
--headless	no display at all; scootctl screenshot reads the framebuffer	agents, tests, screenshots

scoot --nested -- foot        # a window with a terminal in it
scoot --tty -- foot           # the whole console, from a VT
scoot --headless -- foot      # nowhere visible; screenshot it

Everything after -- is one program and its arguments, run once the session is up (Starting a session). scoot --print-default-config emits a starting config file (commented, every default shown); --write places it directly, refusing to overwrite.

Flag	Type	Default	Meaning
--width N, --height N	int	1600x1000	the --headless/--nested output size, 1–65535 per axis. Out of range is a startup error naming the range. Under --nested it is only the size scoot asks for — the host’s configure decides. An [[outputs]] entry’s mode overrides it for the output it names.
--outputs N	int	1	how many outputs --headless creates, 1–8, laid left to right. --nested and --tty warn and ignore it.
--renderer pixman|gles	enum	pixman	which renderer composites each frame (config: [renderer] backend).
--gpu PATH	path	automatic search	which DRM device --tty drives (config: [tty] gpu). Ignored with a warning outside --tty.
--mode WxH	mode	connector preferred	which connector mode --tty picks. Ignored with a warning outside --tty. An [[outputs]] entry’s mode overrides it per connector.
--xwayland	switch	off	run an XWayland server so X11 apps get a DISPLAY (config: [xwayland] enabled; either turns it on). Needs an xwayland build; without one it warns and runs Wayland-only.
--socket PATH	path	$SCOOT_SOCKET, else $XDG_RUNTIME_DIR/scoot.sock	where the IPC control socket lives.
--config PATH	path	$XDG_CONFIG_HOME/scoot/config.toml	load this TOML file instead of searching.
--version	switch	—	print scoot <version> (ipc protocol <N>) and exit; needs no compositor.
--help	switch	—	usage, every request and every action.

scoot msg REQUEST is the scootctl client kept on the compositor binary as a permanent alias — everything under REQUEST is documented in scootctl, not duplicated here.

Starting a session

scoot starts the programs inside the session two ways, which compose rather than compete:

The session script is the -- COMMAND... flag: everything after -- is one program and its arguments, run once the session is up with WAYLAND_DISPLAY, SCOOT_SOCKET and the session environment already set. It is the 20% route — the one with ordering, conditionals, and wait:

~/bin/session.sh

#!/bin/sh
scootbg daemon &      # a wallpaper, on the background layer
scootbar daemon &     # a bar, on the top layer
mako &                # a notification daemon
exec foot             # the terminal the session starts with

scoot --tty -- ~/bin/session.sh

scoot does not wait on the script and does not exit when it exits — fire and forget — and it restarts nothing that dies. Supervision is explicitly out of scope: restarting a crashed bar is a service manager’s job. Exited children are reaped, so nothing lingers as a zombie.

[autostart] is the 80% route — the programs with no ordering or conditionals, as action strings in the config file. Entries run first, in file order, then the -- command: the config declares the session baseline, the script carries the behavior. Spawning the same bar in both places yields two bars — pick one route per program.

Environment scoot reads: $XDG_RUNTIME_DIR (required — a missing one is a one-line startup error), $SCOOT_SOCKET, $XDG_CONFIG_HOME, $XCURSOR_THEME, and the session locale for typing. Environment scoot exports to what it spawns: $WAYLAND_DISPLAY, $SCOOT_SOCKET, $XCURSOR_THEME, $XCURSOR_SIZE, $XDG_CURRENT_DESKTOP=scoot (always), $XDG_SESSION_TYPE=wayland and $XDG_SESSION_DESKTOP=scoot (only where unset — on a logind seat both are logind’s to set), a fresh $XDG_ACTIVATION_TOKEN, and $DISPLAY while the session’s XWayland server is believed live.

Portals need one manual step outside the compositor: D-Bus activation carries its own environment, so the session must export the display into it (under home-manager this copy-over is the module’s job; without the module, it stays manual):

# systemd session started by hand (a session script, not the launcher):
dbus-update-activation-environment --systemd WAYLAND_DISPLAY XDG_CURRENT_DESKTOP
# s6 / seat without a user manager (the webtop target):
dbus-update-activation-environment WAYLAND_DISPLAY XDG_CURRENT_DESKTOP

resources/scoot-portals.conf names which backend serves what once the lookup can find it: everything falls through to gtk, while ScreenCast/Screenshot go to wlr. Install it as scoot-portals.conf in the first of ~/.config/xdg-desktop-portal/, /etc/xdg-desktop-portal/, /usr/share/xdg-desktop-portal/ that your setup provides (xdg-desktop-portal 1.17+ does the rest).

More than one output

--headless --outputs N gives a session N virtual outputs with no second monitor in the building — so per-output behavior is testable. Each output is real: its own wl_output global, its own workspaces and scrolling strip (a window is on exactly one output; nothing scrolls across a boundary), its own exclusive zones (a bar on one output shrinks only that output’s tiling area), its own scale, its own render target (so scootctl screenshot --output 2 answers with the second output’s own pixels). Under --tty every connected monitor is an output like these, named after its connector, placed left to right, added and removed as monitors plug and unplug.

What it is not yet: outputs line up left to right (no position setting; scale and mode are set per output in the file, not from wlr-randr); new windows open on the output under the pointer. Stepping across outputs is bound by default (Super+comma / Super+period, wrapping left and right — see Outputs). A returning monitor gets its windows back: when an output is removed its workspaces are adopted by the remaining output, and when a monitor with a matching identity returns, the still-open ones move back.

Next: Configure — the config file, reload, and what happens when the file is wrong.
